Introduction to Simple Object Access Protocol (SOAP)

SOAP (Simple Object Access Protocol) is a network protocol that allows nodes to exchange structured data. Messages are transferred using the XML format. It notates and transmits data using application layer protocols such as HTML and SMTP. Because protocols like HTTP are already installed on all platforms, SOAP allows processes to communicate across platforms, languages, and operating systems.



SOAP was created in 1998 by Microsoft's Bob Atkinson, Don Box, Dave Winer, and Mohsen Al-Ghosein. Until 2009, the World Wide Web Consortium's XML Protocol Working Group maintained SOAP.



What is the Simple Object Access Protocol (SOAP)?



The Simple Object Access Protocol (SOAP) is a lightweight XML-based protocol used for information exchange in decentralized, distributed application environments. SOAP messages can be sent in any manner required by the applications, as long as both the client and the server use the same method. The current specification only describes one transport protocol binding, HTTP.



SOAP fits perfectly into the world of Internet applications and promises to improve future Internet interoperability for application services. SOAP, in essence, converts method calls into XML strings and sends them to component instances via HTTP.



SOAP XML documents are organized around root elements, child elements that contain values, and other specifications. First, an XML document with a request (the method to be invoked and its parameters) is sent. The server returns a corresponding XML document containing the results.



SOAP does not use Microsoft technology. UserLand, Ariba, Commerce One, Compaq, Developmentor, HP, IBM, IONA, Lotus, Microsoft, and SAP collaborated to create this open standard. In May 2000, SOAP 1.1 was presented to the W3C as an official Internet standard. Microsoft is a strong supporter of SOAP and has included it as a standard interface in the .NET architecture.



A SOAP stack, which is a client-side implementation of the SOAP standard, is made up of libraries and classes that provide helper functions. A significant Web service testing challenge is the existence of several incompatible SOAP stack implementations. So, even though SOAP is intended to be platform- and technology-independent, it is not.



Web services written in.NET, on the other hand, are always compatible with.NET clients because they use the same SOAP stack or library. To avoid interoperability issues, when testing a.NET Web service, you must confirm that the service is compatible with other SOAP stack implementations, such as the Java SOAP stack. SOAP client requests are packaged as HTTP POST or M-POST requests.



Also Read | HTTP vs HTTPS: Definition, Working, and Comparison



How does SOAP Function?



SOAP (Simple Object Access Protocol) is a message specification used to exchange data between systems and applications. A SOAP API is a more structured and formalized approach to developing application programming interfaces (APIs).



Consider SOAP to be the national postal service: It provides a dependable and trusted method for sending and receiving messages between systems (and within enterprise applications). It is more established, dependable, and older—but it can be slower than competing architectural styles such as REST.



SOAP has a generic structure, as does any API framework. Having said that, the architecture of a SOAP API is comparable to that of an HTML DOM.



The following is the structure of a SOAP API:

---



Structure of SOAP

---



The envelope indicates whether an incoming or outgoing XML is SOAP data. Consider this to be the head of an HTML DOM.



1. Envelope:



It designates the XML message as a SOAP message. A SOAP message is an XML document with a header and body encapsulated in an envelope. The problem is in the message's body.



2. Header:



This section is optional. However, when present, it can provide critical information about the applications. The SOAP message's Header element contains additional information. This information could be authentication credentials used by the calling application, for example.



3. Body :



The Body element contains information about the actual message that must be sent from the web service to the calling application. This data includes information about calls and responses. The SOAP message is nothing more than an XML document with the following components.



An Envelope element that identifies the XML document as a SOAP message - This is the SOAP message containing part and is used to encapsulate all of the message's details. This is the SOAP message's root element.



A header element containing header information - The header element may contain information such as authentication credentials that the calling application may use. It may also include the definition of complex types that may be used in a SOAP message. By default, the SOAP message may contain parameters of simple types such as strings and numbers, but it may also contain a complex object.



SOAP requests are simple to create and respond to. A client first generates a service request using an XML document. The XML document is then sent to a SOAP server by a SOAP client. When the server receives the SOAP message, it sends it to the requested server-side application as a service invocation. The requested parameters, return values, and data for the client are returned to the SOAP request handler first, and then to the requesting client. SOAP requests and responses are both sent and received using Hypertext Transfer Protocol Secure (HTTPS) or a similar protocol such as HTTP.



Also Read | What is Web Scraping? Top 5 Tools for Web Scraping





Pros and Cons of Simple Object Access Control:



SOAP allows developers to deploy Web services as quickly as they can create SOAP messages for program calls to existing applications and embed those applications in simple Web pages. However, instead of requiring time-consuming and costly development, developers can use SOAP calls in dedicated applications and build applications that can be dragged onto other people's Web pages.



The official definition, which can be found in the most recent SOAP 1.2 specification, is as follows: "SOAP is a simple protocol for exchanging structured data in a decentralized, distributed environment. SOAP defines an extensible messaging framework using XML technologies, which provides a message construct that can be exchanged over a variety of underlying protocols.



The framework was created to be independent of any programming model or other implementation-specific semantics." This definition gets to the heart of what SOAP is all about. SOAP defines a method for transporting XML messages from point A to point B. (see Figure below). It accomplishes this by providing an XML-based messaging framework that is extensible, adaptable to a wide range of underlying networking protocols, and independent of the programming model.



SOAP is an essential component of service-oriented architecture (SOA) and web services specifications.



SOAP has the following advantages:



1. Independent of the platform and operating system. SOAP can be delivered via several protocols, allowing communication between applications written in various programming languages on both Windows and Linux.



2. Uses the HTTP protocol. Even though SOAP works with a variety of protocols, HTTP is the standard protocol for web applications.



3. Can be transmitted via various network and security devices. SOAP can easily pass through firewalls, whereas other protocols may necessitate special consideration.



However, there are some disadvantages:



1. There is no support for passing data by reference. If multiple copies of the same object are passed at the same time, this can cause synchronization problems.



2. Speed. SOAP's data structure is based on XML. Because XML is mostly human-readable, a SOAP message is relatively simple to comprehend. However, this results in relatively large messages when compared to the Common Object Request Broker Architecture (CORBA) and its remote procedure call (RPC) protocol, which can accommodate binary data. As a result, CORBA and RPC are faster.



3. Other methods are more adaptable. Although SOAP is adaptable, newer methods, such as RESTful architecture, use XML, JavaScript Object Notation, YAML, or any parser required, making them more adaptable than SOAP.



4. SOAP has different levels of support, depending upon the programming language supported. SOAP supports with Python and PHP is not as strong as it is within JAVA and .NET



What is the Difference between SOAP and REST?



SOAP (Simple Object Access Protocol) is a highly strict and secure method of developing APIs that encode data in XML. REST (Representational State Transfer) is a simpler and more flexible method for creating APIs that can transfer data in a variety of formats, including XML, plain text, HTML, and JSON.



SOAP and REST (the latter is an architecture and not a protocol) are both used for web services, but both approach the task differently. While SOAP is a little older, REST (or RESTful web services) has caught up quickly and now provides roughly 70% of the web services available on the Internet.



However, each has distinct advantages. REST, for example, is considered relatively simple, does not only work with XML, is faster, and is lighter than SOAP. While REST gives users a lot of XML freedom (JSON is frequently used), SOAP gives users a choice of protocols. Although HTTP is the most commonly used protocol, SOAP can be used in conjunction with other protocols such as FTP and SMTP.



SOAP also has a significant security advantage: WS-Security (web service security specifications) is firmly embedded in the network protocol. SOAP also improves error handling because a function for request repetition is directly integrated.



Though since SOAP is a messaging protocol, securing SOAP APIs is primarily concerned with preventing unauthorized access to messages (and the user information contained within those messages) received and sent by SOAP APIs. Web Standards (WS) Security, a set of principles that govern the confidentiality and authentication procedures for SOAP messaging, is the primary defense against unauthorized access. Passwords, XML encryption, and security tokens are examples of WS Security-compliant mechanisms.



REST APIs only support standard web security mechanisms like HTTPS. That is, when an application uses HTTPS to send and retrieve a message from a REST API, the message is only secure for the HTTPS connection. That is, the message is only secure during its transit between the client and the service. That is sufficient for public web services, but it may not be sufficient for more sensitive data transfers.



As REST APIs lack the built-in security capabilities or extensions found in SOAP, their security is dependent on the design of the APIs. REST APIs can be built with security features that ensure only authenticated and authorized users have access to them. HTTP basic authentication, JSON web tokens, OAuth, and other methods are commonly used for REST API authentication.



To summarize, SOAP was the first protocol widely used for connecting web services in a service-oriented architecture. RESTful principles are now widely used in the development of distributed applications. SOAP is nearly always restricted to legacy platforms. SOAP is still used in applications that handle online transactions because it is a more rigid and protocol-driven style of API.
